NF250 250W front hub motor with helical gear

NF250 250W front hub motor with helical gear

Short Description:

With good quality of alloy shell, small in size, super light, high efficiency over than 81%, the NF250 hub motor could be perfectly matched with e-City and Mountain bikes. This type of 250W front hub motor could reach 25-32km/h, which could meet your demands of daily life very well. It’s compatible with disc-brake and v-brake, and the cable position could be both left and right.

  • Voltage(V)

    Voltage(V)

    24/36/48

  • Rated Power(W)

    Rated Power(W)

    180-250

  • Speed(Km/h)

    Speed(Km/h)

    25-32

  • Maximum Torque

    Maximum Torque

    45

PRODUCT DETAIL

PRODUCT TAGS

Core Data

Voltage(v)

24/36/48

Rated Power(W)

180-250

Speed(KM/H)

25-32

Maximum Torque

45

Maximum Efficiency(%)

≥81

Wheel Size(inch)

20-28

Gear Ratio

1:6.28

Pair of Poles

16

Noisy(dB)

<50

Weight(kg)

1.9

Working Temperature(℃)

-20-45

Spoke Specification

36H*12G/13G

Brakes

Disc-brake/V-brake

Cable Position

Right/Left

Competitiveness
Our company's motors are highly competitive and can meet the needs of various applications, such as the automotive industry, household appliances industry, industrial machinery industry, etc. They are strong and durable, can be used normally under different temperature, humidity, pressure and other harsh environmental conditions, has good reliability and availability, can improve the production efficiency of the machine, shorten the production cycle of the enterprise.

Case application
After years of practice, our motors can provide solutions for various industries. For example, the automotive industry could use them to power mainframes and passive devices; The home appliances industry could use them to power air conditioners and television sets; The industrial machinery industry can use them to meet the power needs of a variety of specific machinery.

Technical support
Our motor also provides perfect technical support, which can help users quickly install, debug and maintain the motor, reduce the installation, debugging, maintenance and other activities time to a minimum, so as to improve user efficiency. Our company can also provide professional technical support, including motor selection, configuration, maintenance and repair, to meet user needs.

Solution
Our company can also provide customers with customized solutions, according to the specific needs of customers, using the latest motor technology, in the best way to solve the problem, to ensure the stability and reliability of the motor to meet the customer's expectations.

  • Now we will share you the hub motor information.

    Hub Motor Complete kits

    • Light Weight
    • Mini Shape
    • Splendid Appearance
    • High Efficiency
    • Helical Gear For Reduction System
